Free space Acousto-Optic components

AA OPTO-ELECTRONIC: free space Acousto-optic components from 180nm up to 11µm...
See our products

Fiber pigtailed Acousto-Optic components

AA OPTO-ELECTRONIC: fiber pigtailed components from 400nm up to 2200nm...
See our products

RF drivers for Acousto-Optic components

AA OPTO-ELECTRONIC: Radio frequency drivers matched to Acousto-optic performances...
See our products

RF Electronics for Optical applications

AA OPTO-ELECTRONIC: Custom designs and standard Radio frequency electronics for optical applications...
See our products

News

AA introduce a new high frequency DDS (Direct Digital Synthesizer) operating from 10MHz up to 1400MHz. It can be controlled with an analog signal, Digital ...
AA introduce a new Rack Booster for Quantum applications. With 8 embedded power amplifiers 1 to 4 Watts, this is a suitable tool to drive ...
AA introduce a new range of fiber pigtailed phase modulators. They are available from VIS to IR, with a phase resolution of  0.2 degrees. Contact ...
AA introduce a new 200 to 250 watts fixed frequency source, 27.12, 40.68, 80MHz. This source allows digital and analog amplitude amplitude modulation at high ...
The new drivers from AA offer 4 or 8 parallel variable frequency outputs from phase locked DDS. They are suitable for frequency shifters, multi channels ...

Complimentary image from Pegasus Optik GmbH.

Photo of the deflection of a 2 axis RGB deflector type DTSXY-400, showing the scan overlap of colors.

3 colors are entering simultaneouly the AOD (Blue, Red, Green). A Multi-Color-Machine (MCM) from Pegasus Optik GmbH is used with operating wavelengths 635nm, 520nm and 488nm (more info about MCM). The full frequency range of the AOD is swept in a raster scan mode.

For most of the applications, the overlap part of the deflection is used. For narrow wavelength bands, the overlap is very high.

We can get similar ovelaps for Infrared wavelengths.

Carousel Post: No posts found
“ We work every day to provide you with the best standard and bespoke solutions. Your complete satisfaction is our goal. ”

About AA Opto Electronic

AA OPTO-ELECTRONIC proposes one of the most complete range of standard Acousto-optic components and associated Radio frequency drivers. AO devices cover wavelengths from 180 nm to 11 µm. These products are available for rapid delivery in any quantity. In case you do not find a product which follows your need, then we will be pleased to study a custom device.

The range of RF drivers cover from DC to 3 GHz and up to 500 W. These drivers are matched to AO devices. AA also propose a large range of customized electronics as well as microwave passive components and broadband power amplifiers up to 50 GHz, 1 KW.

AA was founded in 1979, under the name «Automates et Automatismes». It became a limited company in 1988 under the new name of AA Sa, specialising in acousto-optic components and their associated RF drivers. AA is a world leader in the manufacturing of quality Acousto-optic and radio frequency devices. Close collaboration with universities and research institutes, provided invaluable knowledge and experience in the design and manufacturing processes of Acousto-optic devices and radio-frequency sources. Continuous R&D keeps pace with advances in laser and electronic technology to ensure AA continues to offer state-of-the-arts products. AA offers its customers solutions from prototype design to large volume manufacturing thanks to its internal resources and In-house capabilities. Our Headquarter is located in ORSAY, near Paris in France. This is also our optical manufacturing center. All RF drivers are manufactured in our St Avertin plant, located 200 kms south of Paris.
